Resultstore Schema

Entity Relationships

BENCHMARK Table

One entity per Benchmark configuration. Describes a benchmark including its parameters.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
suite	text	Benchmark suite as it appears in the plan
name	text	Benchmark name as it appears in the plan
type	text	Benchmark type as it appears in the plan
image	text	Benchmark container image identifier as it appears in the plan
params_hash	char(64)	SHA256 hash of the params dictionary as they appear in the plan
roles_hash	char(64)	SHA256 hash of the roles dictionary as they appear in the plan

CPU Table

One entity per CPU contained within a node. Describes the set of CPUs that a node contains.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
desc	text	arch-specific descriptor, encoded in JSON
cpu_index	smallint	Logical CPU index
node_id	bigint (FK)	Node ID relates CPUs to node

ERROR Table

One entity per error that occured during running the benchmark. A single benchmark invocation generates 0 or 1 error entities. If an error is generated, no results are generated for the benchmark. Examples of possible errors include the container side rejecting benchmark parameters, or the benchmark timing out.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
timestamp	timestamp	Approximate time at which error was emitted. Errors are stamped when passed back to host and there is latency between generating the error on the SUT and passing it to the host
sut_id	bigint (FK)	SUT ID relates error to SUT
swprofile_id	bigint (FK)	swprofile ID relates error to swprofile
benchmark_id	bigint (FK)	Benchmark ID relates error to Benchmark
rolemap_id	bigint (FK)	Rolemap ID relates error to rolemap
role_id	bigint (FK)	Role ID relates error to role that generated the error
session_uuid	uuid	Universally Unique ID representing the boot session on the SUT that the result was generated during. Conceptually, a new UUID is generated each time the SUT is rebooted. Used to group results and errors from the same session
error	int	Error code

NODE Table

One entity per node. Describes a unique node within a SUT. A node is a machine or device that runs a single instance of Linux. A SUT may be composed of 1 or more nodes.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
sut_id	bigint (FK)	SUT that the node belongs to
name	text	Node friendly name as it appears in the plan
host_name	text	result of uname -n
architecture	text	result of uname -m
cpu_count	smallint	Number of CPUs in the system
cpu_info_hash	char(64)	SHA256 hash of all the CPU info structures
numa_count	smallint	Number of NUMA nodes in the system
ram_sz	bigint	Total RAM in the system in bytes
hypervisor	text	The name of the hypervisor if running in a virtual machine. (e.g. ‘kvm’, ‘hyper-v’ etc.) else empty
product_name	text	The DMI product_name, if available, else empty
product_serial	text	The DMI product_serial, if available, else empty
mac_addrs_hash	char(64)	SHA256 hash of the sorted list of permanent MAC addresses from physical devices attached to the node

PARAM Table

One entity per param specified for a benchmark. Describes the set of parameters that a benchmark is configured with.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
name	text	Param name as it appears in the plan
value	text	Param value as it appears in the plan
benchmark_id	bigint (FK)	Benchmark ID relates Param to Benchmark

RESULT Table

One entity per result. A single benchmark invocation returns 1 or more results.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
timestamp	timestamp	Approximate time at which result was collected. Results are stamped when passed back to host and there is latency between generating the result on the SUT and passing it to the host
resultclass_id	bigint (FK)	ResultClass ID relates Result to ResultClass
sut_id	bigint (FK)	SUT ID relates Result to SUT
swprofile_id	bigint (FK)	swprofile ID relates Result to swprofile
rolemap_id	bigint (FK)	Rolemap ID relates result to rolemap
role_id	bigint (FK)	Role ID relates result to role that generated the result
session_uuid	uuid	Universally Unique ID representing the boot session on the SUT that the result was generated during. Conceptually, a new UUID is generated each time the SUT is rebooted. Used to group results and errors from the same session
value	double	Numerical result value

RESULTCLASS Table

One entity per ResultClass. Every Result belongs to a single ResultClass.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
benchmark_id	bigint (FK)	Benchmark ID relates ResultClass to Benchmark
name	text	Result name (e.g. duration or memory)
unit	text	Unit of the result value (e.g. seconds, ops/sec, etc)
improvement	enum	Either ‘bigger’ or ‘smaller’: Determines whether a bigger or smaller value represents an improvement in performance

ROLE Table

Describes a role that a benchmark performs.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
name	text	Role name as it appears in the plan
benchmark_id	bigint (FK)	Benchmark ID relates role to benchmark

ROLEMAP Table

Describes the mapping of a benchmark’s roles to the nodes they execute on. Composed of 1 or more rmdescs.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
rmdescs_hash	char(64)	SHA256 hash of all the rmdesc structures

RMDESC Table

Describes the mapping of a single benchmark role to the node it executes on.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
rolemap_id	bigint (FK)	Rolemap that the rmdesc belongs to
role_id	bigint (FK)	Role that is being mapped
node_id	bigint (FK)	Node that the role is mapped to

SUT Table

One entity per SUT. Describes a unique SUT independent of its SW profile. A SUT is composed of 1 of more nodes.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
name	text	SUT friendly name as it appears in the plan
nodes_hash	char(64)	SHA256 hash of all the node structures

SWPROFILE Table

One entity per software profile. Describes a software configuration including the kernel under test.

key	type	description
id	bigserial (PK)	Primary key. Auto-incrementing integer
name	text	swprofile friendly name as it appears in the plan
kernel_name	text	Output from uname -r
kernel_git_sha	char(40)	Git SHA for kernel source (if available)
kernel_kconfig_full_hash	char(64)	SHA256 hash of kernel config (e.g. from /boot/config-$(uname -r), or /proc/config.gz) (if available)
kernel_cmdline_full_hash	char(64)	SHA256 hash of /proc/cmdline
userspace_name	text	Output from lsb_release -d
cmdline	text	Alphabetically sorted command line parameters, as specified in plan, as a newline separated string
sysctl	text	Alphabetically sorted applied sysctl settings, as specified in plan, as a newline separated string
bootscript	text	Bootscript passed as it appears in plan
